2025 Sprinter Van Interior

The new 2025 Sprinter is available in four configurations, three of which are different types of vans, and one of which is a chassis cab. No matter which of the Sprinter models you can upholster the Sprinter seats with Maturin Black Fabric, Caluma Black Fabric, or Black Leatherette.

How do the Sprinter models differ? The most important difference between the 12-passenger Sprinter van interior and the Cab Chassis interior comes down to the Sprinter interior dimensions. Compare key measurements for each option with Mercedes-Benz of Manhattan near Brooklyn. Then, fill out a pre-approval and contact our knowledgeable staff to arrange to see the Sprinter van interior with your own eyes at our showroom in New York.

2025 Sprinter Interior Dimensions

As we mentioned, the 12-passenger Sprinter van interior differs in size from the Cargo, Chassis Cab, and Crew Van variants. On top of that, each of these vans can be configured with a 144-inch wheelbase or 170-inch wheelbase and standard roof or high roof, meaning that there’s extraordinary variability in size between the Sprinter van interior measurements for each configuration. Bearing in mind that the Chassis Cab can only be configured with the standard roof, compare the Sprinter interior dimensions for each body style below:

Cargo Van

144-Inch Wheelbase, Standard Roof

Class 2500 Standard Output / High Output / High Output AWD

• Seating capacity: 2-3
• Interior height: 68 inches
• Cargo bed length: 133 inches
• Load height: 28 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: 54 square feet / 54 square feet / 54.3 square feet
• Cargo volume: 319 cubic feet

Class 3500 Standard Output / High Output

• Seating capacity: 2-3
• Interior height: 79 inches
• Cargo bed length: 104 inches
• Load height: 29 inches
• Maximum cargo bed length: 104 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet / 81 square feet
• Cargo volume: 223 cubic feet

Class 3500XD High Output / High Output AWD

• Seating capacity: 2-3 / 3
• Interior height: 79 inches
• Cargo bed length: 133 inches
• Load height: 31 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet
• Cargo volume: 281 cubic feet

Cargo 4500 High-Output

• Seating capacity: 2-3
• Interior height: 68 inches
• Cargo bed length: 133 inches
• Load height: 29 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet
• Cargo volume: 281 cubic feet

144-Inch Wheelbase, High Roof

Class 2500 Standard Output / High Output / High Output AWD

• Seating capacity: 2-3
• Interior height: 79 inches
• Cargo bed length: 133 inches
• Load height: 31 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 74 inches
• Loading area: 54.3 square feet
• Cargo volume: 374 cubic feet

Class 3500 Standard Output / High Output

• Seating capacity: 2-3
• Interior height: 79 inches
• Cargo bed length: 133 inches
• Load height: 29 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet
• Cargo volume: 329 cubic feet

Class 3500XD High Output / High Output AWD

• Seating capacity: 2-3 / 3
• Interior height: 79 inches
• Cargo bed length: 133 inches
• Load height: 29 inches / 31 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet
• Cargo volume: 329 cubic feet

Class 4500 High-Output

• Seating capacity: 2-3
• Interior height: 79 inches
• Cargo bed length: 133 inches
• Load height: 29 inches
• Maximum cargo bed length: 133 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 51 square feet
• Cargo volume: 281 cubic feet

170-inch Wheelbase, High Roof

Class 2500 Standard Output / High Output / High Output AWD

• Seating capacity: 2-3 / 3 / 2-3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 173 inches / 174 inches
• Load height: 27 inches / 27 inches / 31 inches
• Maximum cargo bed length: 174 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: N/A for standard output / 74 square feet
• Cargo volume: 488 cubic feet

Class 3500 Standard Output / High Output

• Seating capacity: 2-3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 174 inches
• Load height: 29 inches
• Maximum cargo bed length: 174 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 70 square feet
• Cargo volume: 430 cubic feet

Class 3500XD High-Output / High-Output AWD

• Seating capacity: 2-3 / 3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 174 inches
• Load height: 29 inches / 31 inches
• Maximum cargo bed length: 174 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 70 square feet
• Cargo volume: 430 cubic feet

Class 4500 High-Output

• Seating capacity: 2-3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 174 inches
• Load height: 29 inches
• Maximum cargo bed length: 174 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 70 square feet
• Cargo volume: 430 cubic feet

170-Inch Extended Wheelbase, High Roof

Class 2500 Standard Output / High Output / High Output AWD

• Seating capacity: 2-3 / 2-3 / 3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 189 inches
• Load height: 27 inches / 27 inches / 31 inches
• Maximum cargo bed length: 189 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: 81 square feet
• Cargo volume: 533 cubic feet

Class 3500 Standard Output / High Output

• Seating capacity: 2-3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 189 inches
• Load height: 29 inches
• Maximum cargo bed length: 189 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 81 square feet
• Cargo volume: 469 cubic feet

Class 3500XD High Output / High Output AWD

• Seating capacity: 2-3 / 3
• Standing height: 79 inches / 79.1 inches
• Interior height: 79.1 inches
• Cargo bed length: 189 inches
• Load height: 29 inches / 31 inches
• Maximum cargo bed length: 189 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 80.1 square feet / 78 square feet
• Cargo volume: 469 cubic feet

Class 4500 High-Output

• Seating capacity: 2-3
• Standing height: 79 inches
• Interior height: 79 inches
• Cargo bed length: 189 inches
• Load height: 28 inches
• Maximum cargo bed length: 189 inches
• Cargo width at wheelhouse: 39 inches
• Max width at floor: 70 inches
• Loading area: 78 square feet
• Cargo volume: 469 cubic feet

Crew Van

144-Inch Wheelbase, Standard Roof

Class 2500 standard output / high output / high output AWD

• Seating capacity: 5
• Standing height: 65 inches
• Interior height: 77 inches
• Cargo bed length: 104 inches
• Load height: 28 inches / 28 inches / 31 inches
• Maximum cargo bed length: 104 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 240 cubic feet / 240 cubic feet / 223 cubic feet

144-Inch Wheelbase, High Roof

Class 2500 standard output / high output / high output AWD

• Seating capacity: 5
• Standing height: 77 inches
• Interior height: 77 inches
• Cargo bed length: 104 inches
• Load height: 28 inches / 28 inches / 31 inches
• Maximum cargo bed length: 104 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 279 cubic feet

170-Inch Wheelbase, High Roof

Class 2500 standard output / high output / high output AWD

• Seating capacity: 2-3 / 5
• Standing height: 77 inches / 77 inches / 111 inches
• Interior height: 77 inches
• Cargo bed length: 144 inches
• Load height: 27 inches / 27 inches / 31 inches
• Maximum cargo bed length: 144 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 396 cubic feet

Passenger Van

144-Inch Wheelbase, Standard Roof

Class 2500 standard output / high output / high output AWD

• Seating capacity: 12
• Standing height: N/A
• Interior height: 64 inches
• Cargo bed length: 36 inches
• Load height: N/A
• Maximum cargo bed length: 36 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 70 cubic feet

144-Inch Wheelbase, High Roof

Class 2500 standard output / high output / high output AWD

• Seating capacity: 12
• Standing height: 76 inches
• Interior height: TBD
• Cargo bed length: 36 inches
• Load height: N/A
• Maximum cargo bed length: 36 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 82 cubic feet

170-Inch Wheelbase, High Roof

Class 2500 standard output / high output

• Seating capacity: 15
• Standing height: 75.5 inches
• Interior height: 76 inches
• Cargo bed length: 48 inches
• Load height: 27 inches
• Maximum cargo bed length: 48 inches
• Cargo width at wheelhouse: 53 inches
• Max width at floor: 70 inches
• Loading area: TBD
• Cargo volume: 117 cubic feet

Cab Chassis

144-Inch Wheelbase, Standard Roof

Class 3500XD High Output / High Output AWD / Class 4500 High-Output

• Seating capacity: 2-3

170-Inch Wheelbase, Standard Roof

Class 3500XD High Output / High Output AWD / Class 4500

• Seating capacity: 2-3

See the 12-Passenger Sprinter Van Interior Near Union City

Now that you’ve read about the 2025 Sprinter dimension and the upholstery options available for the 2025 Sprinter seats, compare the 2025 Sprinter interior van sizes for yourself at Mercedes-Benz of Manhattan. Call our team at 212-629-1600 to arrange your test drive at our Manhattan showroom. While you’re here, explore our Sprinter research guides for helpful information about the Sprinter exterior and Sprinter engine options.
